RC FRONT HARVESTER FOR BOBCAT AND TRACTORS SICMA
Adopting the most advanced technology, the RC combines the vibrating head with the reverse umbrella frontally coupled on the tractors, either wheeled or tracked. The kit is coupled by means of a reinforced bracket fixed to the tractor’s frame and provided with an independent hydraulic system (rear oil tank) operated by the tractor’s PTO, of at least 90 HP. On tracked tractors, the kit is coupled on the frontal bulldozer (if present). The frontal position of the kit guarantees the best visual to the operator who open the reverse umbrella once the tree is tighten by the jaw’s head, for the fast and integral harvest of the tree. It is suitable for medium size with single-trunk trees. The umbrella diameter ranges between 5 and 7 m to best fit the different growing conditions (tree density). Upon request, the umbrella case can be in aluminum, even equipped with lateral dehuskers (for almonds). The kit can be completely removed at the end of the harvesting season.
The RC is the solution for the harvest of hanging fruits that uses your tractor, wheeled or tracked...
| Vibrating Head | New Generation at high frequencies, self-centring, self-braking. Two vibrating speeds |
| Umbrella's diameter | Ø 5, 6 or 7m |
| Case capacity | 250kg |
| Controls | Hydraulic distributor with levers and electric switch |
| Hydraulic circuit | Closed hydraulic circuit composed by vibration pump, services pump and electrohydraulic valves. Hydraulic oil tank separated from the tractor circuit. Actuated by the cardan power shaft PTO (540 rpm) |
| Activation | PTO (540 rpm) |
| Weight & Dimensions | |
| Total Length | 3.100mm (centerwheel-case with extension retracted arm) |
| Total width | 2.300mm |
| Options | Umbrella bar extensions - Mechanically tilting umbrella - Electro-hydraulic joystick - Electronic Joystick (mandatory for tractors with cabin) |
| CROP | OLIVE*WALNUT*PEANUTS*ALMOND*HAZELNUT*PECAN |
- Stock: Pre-Order
- Model: ΜΕ.02.323
